Krypton® Multi

Multi-channel water monitoring system

Controlled and reliable measurements are driven by Kuntze Krypton® systems. The Krypton® Multi measuring system includes all customer needs for a disinfectant measurement: instrument, software, sensors, flow cell, and cables.

The Krypton® Multi is a measurement system for disinfectant, pH and temperature. ORP/redox, conductivity, or an additional disinfectant measurement can be added. The Krypton® Multi system is delivered fully assembled and ready to use.

Krypton® Multi‘s water measurement process can be controlled at any time, from any place, on any device via Kuntze‘s Cloud Connect® service. All Kuntze products are made by Kuntze Instruments in Hartha, Germany.



Applications

Process Water

Process Water

Disinfection

Disinfection

Drinking water

Drinking Water

Food & Beverage

Food & Beverage

Krypton Multi Krypton Multi

Parameter

Disinfectants

  • Free Chlorine, Chlorine Dioxide, Total Chlorine: up to 1000 µg/l, 5.00 / 10.00 / 20.00 mg/l

  • Ozone: up to 1000 µg/l, up to 5.00 / 10.00 mg/l

  • Hydrogen peroxide: up to 30.00 mg/l

Temperature

  • 32.. 122 °F

pH

  • 0..14.00 pH

Redox potential (optional)

  • -1500.. +1500 mV

5th measuring input (optional)

  • Conductivity: up to 100.0 mS/cm

6th measuring input (optional / DIS 2)

  • Free Chlorine, Total Chlorine: up to 1000 µg/l, up to 5.00 / 10.00 / 20.00 mg/l

Digital inputs

  • Flow control, external controller stop, 2x level control, activation 2nd or 3rd control parameter set

StabiFlow®

StabiFlow® is an assembly for precise measurement of disinfectants. The values are:

  • Constant flow of approx. 30 l/h

  • Stable, precise and reliable measurements

  • Cost reduction due to increased life expectancy of the sensors

ASR®

ASR® is Kuntze's patented automatic sensor cleaning

  • ASR® keeps the electrode surfaces automatically clean and reduces maintenance efforts

  • ASR® is available for measurement of Free Chlorine, Chlorine Dioxide, Ozone and Hydrogen Peroxide

Cost reduction due to less maintenance

  • No manual cleaning

  • No refill of chemical or physical agents

  • Massively reduced calibration demand
