Key Features:
Bare Sensor Technology
Kuntze exclusively employs bare sensor technology, providing attractive advantages over both DPD and covered membrane sensor measurements.
Download the Ozone Technology Comparison Chart
Kuntze engineered core components, optimized for precise and reliable online measurements.
Argon Stabiflow ®
The Argon Stabiflow® is a critical component of the Kuntze disinfectant measurement. The Argon StabiFlow® assembly eliminates deviations caused by changing flow rates and can be used with any of Kuntze disinfectant sensors.
Compensation
All amperometric free chlorine measurements (not just Kuntze's) are subject to variables that either need to be controlled, buffered, and/or measured for compensation. A free chlorine measurement can be produced when the below variables are attended to.
Compensation
As with most electrochemical measurements, the Kuntze bare sensor measurement offers integrated temperature compensation. The temperature sensor acts two-fold as the integrated flow switch.
Kuntze measuring instruments come standard with universal power supplies that accept:
Standard: 85-265 VAC 50-60 Hz.
Optional: 24 VDC versions available
Flow pressure minimum: 5 psi at 20C
Flow pressure maximum: 87 psi at 68F or 6 Bar at 20C
Flow rate minimum: 9 gph or 35 l/hr
Flow rate maximum: NA
The Argon Stabiflow flow regulator is designed to manage and control the flow rate across the Kuntze Zirkon measuring electrodes. This ensures proper DIS measurement and improves overall sensor life expectancy.
The internal diaphragm regulates the analyzer outlet to 8 gph or 30 l/hr
Kuntze amperometric chlorine measuring technology complies with EPA Method 334.0 hardware guidelines.
