Zirkon® pH Universal

Zirkon® pH Universal is a sensor for measuring pH.

Benefits

  • Low maintenance due to gel filling

  • High precision due to use of high alkaline high temperature glass

Applications

Disinfection

Disinfection

Drinking Water

Drinking Water

Food & Beverage

Food & Beverage

Zirkon® pH Universal Zirkon® pH Universal Zirkon® pH Universal

Measuring Parameter

  • 0.. 14 pH



Ambient Conditions

  • Min. conductivity: > 150 µS/cm

  • Temperature: -5.. +70 °C  (23.. 158 °F)

  • Pressure:

    • Plug PG: < 2 bar at 20 °C (< 29 psi at 68 °F)

    • Resin shaft: < 1 bar at 20 °C (< 14,5 psi at 68 °F)

    • PG 13.5 loose: < 1 bar at 20 °C (< 14,5 psi at 68 °F)

Zirkon® pH Fluoride

Zirkon® pH Fluoride is a sensor for measuring pH in fluoride containing media.

Benefits

  • Fluoride resistant

  • Low maintenance by gel filling

  • Long life expectancy by refillable reference electrode

Applications

Fluoride Containing Media

Fluoride Containing Media

Zirkon® pH Fluoride Zirkon® pH Fluoride

Measuring Parameter

  • 0.. 11 pH

Ambient Conditions

  • Conductivity:

    • 3M KCl: > 50 µS/cm

    • Tepox gel: > 150 µS/cm

  • Temperature: 0.. +60 °C  (32.. 140 °F)

  • Pressure:

    • Plug PG: 0.. 10 bar at 20 °C (0.. 145 psi at 68 °F)

    • PG 13.5 loose: < 1 bar at 20 °C  (< 14.5 psi at 68 °F)

    • KCl pressure attachment: < 6 bar at 20 °C  (< 87 psi at 68 °F)

  • Pressure:

    • PTFE: < 10 bar at 20 °C (< 145 psi at 68 °F)

    • Hole: < 1 bar pressureless (< 14.5 psi)

    • Zircon: < 2 bar at 20 °C (< 29 psi at 68 °F)

    • Platinum: < 2 bar at 20 °C (< 29 psi at 68 °F)

Versions

Type/Configuration Description Article number

205012100

pH sensor: zircon junction, Tepox gel, S8 plug (swivel PG 13.5), 120 mm
24132410K
24132400K

205072100

pH sensor: PTFE junction, Tepox gel, S8 plug (swivel PG 13.5), 120 mm
24132420K
24132300K

Zirkon pH Pool

Zirkon® pH Pool is a sensor for measuring pH particularly in pool and spa applications.

Benefits

  • Low maintenance

  • Higher life expectancy by KCl reservoir

Applications

Pool & Spa

Pool & Spa

Zirkon pH Pool Zirkon pH Pool

Measuring Parameter

  • 0.. 14 pH

Ambient Conditions

  • Min. conductivity: > 150 µS/cm

  • Temperature: -5.. +70 °C  (23.. 158 °F)

  • Max. pressure: 2 bar at 20 °C  ( 29 psi at 68 °F)

Versions

Type/Configuration Description Article number
24132700K

Zirkon® pH Process

Zirkon® pH Process is a sensor for measuring pH in soiled media.

Benefits

  • Low maintenance by gel or solid filling

  • Dirt resistant by premium-quality junctions

Applications

Waste Water Treatment

Waste Water Treatment

Process Water

Process Water

Zirkon® pH Process Zirkon® pH Process Zirkon® pH Process

Measuring Parameter

  • 0.. 14 pH

Ambient Conditions

  • Conductivity: > 150 µS/cm

  • Temperature: 0.. +70 °C  (32.. 158 °F)

  • Pressure:

    • Plug PG: <10 bar at 20 °C (145 psi at 68 °F)

    • PG 13.5 loose: < 1 bar at 20 °C  (< 14.5 psi at 68 °F)

  • Pressure:

    • PTFE: < 10 bar at 20 °C (< 145 psi at 68 °F)

    • Hole: < 1 bar pressureless (< 14.5 psi)

    • Platinum: < 2 bar at 20 °C (< 29 psi at 68 °F)

Versions

Type/Configuration Description Article number
24132150K

203032320

pH sensor: platinum junction, Tepox gel, S7 plug, 160 mm
24132140K
24132120K
24132121K
24132810K

203038390

pH double chamber sensor: Platinum junction, Tepox gel, Reference system: 3M KCl liquid, S7 plug, 220mm
24132501K

Zirkon® pH Process HT

Zirkon® pH Process HT is a sensor for measuring pH in high temperature applications.

Benefits

  • Low maintenance

  • Temperature stable up to max. 135 °C (275 °F)

Applications

High Temperature Application

High Temperature Application

Process Water

Process Water

Sterilisable Application

Sterilisable Application

Zirkon® pH Process HT Zirkon® pH Process HT Zirkon® pH Process HT

Measuring Parameter

  • 0.. 14 pH

Ambient Conditions

  • Conductivity: > 150 µS/cm

  • Temperature: -5.. +135 °C  (23.. 275 °F)

  • Pressure:

    • PTFE: < 10 bar at 20 °C (< 145 psi at 68 °F)

    • Zircon: < 2 bar at 20 °C (< 29 psi at 68 °F)

Versions

Type/Configuration Description Article number
24132122K

Zirkon® pH Coating

Zirkon® pH Coating is a sensor for measuring pH especially for suspensions and varnish.

Benefits



  • Junction protectable

  • Fluoride resistant

  •

  • According to DIN 55659 for pH measurement in electrophoretic dip painting

Applications

Laboratory

Laboratory

Fluoride Containing Media

Fluoride Containing Media

Zirkon® pH Coating

Measuring Parameter

  • 1,0.. 11,0 pH

Ambient Conditions

  • Conductivity:

    • 3M KCl: > 50 µS/cm

    • Solid electrolyte: > 150 µS/cm

  • Temperature: 0.. +60 °C  (32.. 140 °F)

  • Pressure:

    • PG 13.5 loose: < 1 bar at 20 °C  (< 14.5 psi at 68 °F)

    • KCl pressure attachment: < 6 bar at 20 °C  (< 87 psi at 68 °F)

    • Hole junction:  < 1 bar at 20 °C  (< 14.5 psi at 68 °F)

Versions

Type/Configuration Description Article number
24132320K

Zirkon® pH Process Refill

Zirkon® pH Process Refill is a refillable sensor for measuring pH in process water.

Benefits

  • Long life expectancy by refillable reference electrode

  • High precision by use of high alkaline high temperature glass

Applications

Process Water

Process Water

Drinking Water

Drinking Water

Food & Beverage

Food & Beverage

Waste Water Treatment

Waste Water Treatment

Zirkon® pH Process Refill Zirkon® pH Process Refill Zirkon® pH Process Refill

Measuring Parameter

  • 0.. 14 pH

Ambient Conditions

  • Conductivity: > 50 µS/cm

  • Temperature: 0.. +100 °C  (32.. 212 °F)

  • Pressure:

    • KCl pressure attachment: <6 bar at 20 °C (87 psi at 68 °F)

    • PG 13.5 loose: < 1 bar at 20 °C  (< 14.5 psi at 68 °F)

Versions

Type/Configuration Description Article number
24132040K
24132050K

204017390

pH double chamber sensor: zircon junction, electrode and reference system 3M KCI liquid , 220mm, ceramic junction, S7 plug, 220 mm
24132510K

Zirkon® pH Process Pure

Zirkon® pH Process Pure is a refillable sensor for measuring pH in very low conductivities.

Benefits

  • Long life time by refillable reference electrode

  • Measurement in media with very low conductivities by a higher flow rate

Applications

Ultra Pure Water

Ultra Pure Water

Zirkon® pH Process Pure Zirkon® pH Process Pure

Measuring Parameter

  • 0.. 14 pH

Ambient Conditions

  • Conductivity:

    • 3x Zircon: > 0.1 µS/cm

    • Glass sleeve: > 0.1 µS/cm

  • Temperature: 0.. +100 °C  (23.. 212 °F)

  • Pressure:

    • KCl pressure attachment: <6 bar at 20 °C (87 psi at 68 °F)

    • PG 13.5 loose: < 1 bar pressureless  (< 14.5 psi)

    • Glass sleeve: < 1 bar pressureless  (< 14.5 psi)

Versions

Type/Configuration Description Article number
24132070K

202061320

pH sensor: glass sleeve, 3M KCl, S7 plug, 160 mm
24132010K

Zirkon® REF Process Refill

Zirkon® REF Process Refill is a refillable reference sensor. The sensor is used as a reference point for other electrodes with relative potentials e.g. in pH or ORP measurements.

Benefits

  • Long life time by refill

  • Sensor protection via electrolyte bridge

Applications

Process Water

Process Water

Waste Water Treatment

Waste Water Treatment

Ultra Pure Water

Ultra Pure Water

Zirkon® REF Process Refill

Measuring Parameter

Reference point for other sensors with relative potentials e.g. in pH or ORP measurements.

Ambient Conditions

  • Conductivity:

    • Platinum junction: < 50 µS/cm

    • Zircon diaphragma: > 50 µS/cm

  • Temperature: -5.. +100 °C  (23.. 212 °F)

  • Pressure:

    • KCl pressure attachment: <6 bar at 20 °C (87 psi at 68 °F)

    • PG 13.5 loose: < 1 bar at 20 °C  (< 14.5 psi at 68 °F)

Versions

Type/Configuration Description Article number

224E20000

electrolyte bridge: zircon junction, 160 mm
24133800K

224E30001

electrolyte bridge: 2 x platinum junction, 160 mm
24133830K

224B21320

reference electrode: zircon junction, 3M KCl liquid, S7 plug, 160 mm
24133000K
